Oak Pergola Styles, Specifications & Prices (3×3 m and 4×4 m)

At Timber Solution, we design and manufacture a wide range of oak pergolas — from timeless, classic lattice designs to sleek, modern structures. Every pergola is handcrafted from premium European oak and can be supplied as a pre-cut kit or a fully bespoke build tailored to your space.

We use substantially larger oak sections than many competitors, ensuring greater strength, rigidity, and long-term durability. The price of each oak pergola depends on the beam sizes and design features selected by the client.

Standard Oak Pergola Specifications

Every Timber Solution pergola includes:

• Pre-cut oak posts: 145 × 145 mm
• Oak headplates: 100 × 145 mm to 145 × 145 mm (depending on style and span)
• Oak braces: 50 × 150 mm
• Joists / rafters: 60 × 140 mm with a 150 mm overhang
• Traditional kild dried oak pegs M16

These dimensions provide exceptional stability and a premium appearance. Some pergola models include additional design features — such as lattice panels, trellis, slatted sides, or feather-edge cladding — many of which can be added at no extra cost. You can explore all available upgrades and design variations on our website.

Example Oak Pergola Prices

Below are guide prices for our most popular sizes and styles, including VAT (installation not included):

3 × 3 m Pergolas

• Classic Pergola with Trellis: £2,460
• Traditional Style Pergola: £2,490
• Modern Style Pergola: £2,070

4 × 4 m Pergolas

• Classic Pergola with Trellis: £3,270
• Traditional Style Pergola: £3,270
• Modern Style Pergola: £2,370

Customisation and Bespoke Options

If you have a specific vision, our bespoke design service allows you to modify any pergola to suit your space, materials, or budget. We can adjust:

• Beam sizes and post sections
• Roof type (open, slatted, or covered)
• Detailing such as lattice, trellis, or panel inserts
• Joinery style and finish

All pergolas are CNC-machined for precision, ensuring perfect joinery and easy installation on-site. Whether you’re enhancing a traditional garden or creating a modern outdoor living area, Timber Solution offers one of the largest selections of oak pergola styles in the UK.

Factors That Affect Oak Pergola Installation Time

Installing a 3 × 3 m oak pergola is usually a 2–3 day job, but the exact time can vary depending on several important factors:

Weather Conditions

• Rainy weather: Post holes may fill with water, and concrete cannot set properly. This delays work by 1–2 days.
• Windy weather: Handling heavy oak beams becomes unsafe and slows down assembly.

Carpenter Skills & Team Experience

• An experienced oak frame carpenter can align posts and assemble joints faster.
• Less experienced installers may take longer to square the structure and fit beams securely.

Quality & Preparation of the Oak Frame

• Factory-prepared kits (with joints pre-cut and mortise/tenons ready) reduce installation time dramatically.
• If joints need cutting or adjusting on-site, it adds extra hours or even another day.

Weight of the Beams

• Oak is extremely dense. A 150 × 150 mm post (3 m long) can weigh around 50–70 kg.
• Main beams (spanning 3 m, 200 × 100 mm or larger) can weigh 60–90 kg each.
• Lifting requires at least 2 strong workers, or even machinery for larger spans.

Day 1 – Groundworks & Post Setup
Time: 6–8 hrs (full day)
Team: 2 workers
Cost: ~£400

Day 2 – Frame Assembly
Time: ~6 hrs (full day)
Team: 2 workers
Cost: ~£400

Day 3 – Finishing Touches (optional)
Time: 3–5 hrs (half day – full day)
Team: 1–2 workers
Cost: ~£200–£400

Total Labour Estimate
Basic installation (2 days): ~£800
Full installation with finishes (3 days): ~£1,000–£1,200
